Mushroom Shelf Unloading Machine (Automatic Mushroom Basket Unloading Machine)
The SUMXH12A Mushroom Shelf Unloading Machine is an intelligent automatic unloading system designed for transferring mushroom cultivation baskets from growing shelves to transport areas, featuring PLC control, automatic detection, flexible shelf adjustment, and high-efficiency operation to reduce manual handling, improve production efficiency, and support large-scale mushroom cultivation.
Key Specifications
|
Model |
SUMXH12A |
|
Equipment Type |
Mushroom Shelf Unloading Machine |
|
Main Function |
Automatic unloading and transferring mushroom cultivation baskets |
|
Application |
Mushroom bag basket transportation from cultivation shelves |
|
Power |
1.8 kW |
|
Unloading Efficiency |
10-12 baskets/minute |
|
Machine Weight |
450 kg |
|
Machine Dimension |
1600 × 2000 × 2600 mm |
|
Control System |
PLC Intelligent Control |
|
Operation Mode |
Automatic Mode + Manual Mode |
|
Shelf Compatibility |
Adjustable shelf layers |
|
Basket Arrangement |
Single-row / Double-row Adjustable |
|
Detection System |
Automatic Detection System |
|
Alarm Function |
Fault Alarm System |
|
Automation Level |
Fully Automatic |
Product Description
The SUMXH12A Mushroom Shelf Unloading Machine is an advanced automation solution designed for modern edible mushroom cultivation factories. It is mainly used to automatically remove mushroom cultivation baskets from multi-layer growing shelves and transfer them to the next production stage, such as harvesting, transportation, or processing.
In large-scale mushroom cultivation facilities, thousands of cultivation baskets need to be moved between growing rooms and production areas. Traditional manual unloading requires significant labor, creates high physical workload, and reduces overall production efficiency. The SUMXH12A provides an automated solution by replacing manual basket unloading operations with precise mechanical handling.
The machine adopts an intelligent PLC control system with automatic detection and fault alarm functions. It can monitor operating conditions in real time and ensure stable unloading performance. The equipment supports both automatic and manual operation modes, allowing convenient switching during production adjustments, maintenance, or special operating conditions.
The SUMXH12A is designed with flexible shelf compatibility. The number of shelf layers and loading arrangement can be adjusted according to different mushroom cultivation room layouts. It supports both single-row and double-row basket handling, making it suitable for various multi-layer cultivation systems.
With an unloading efficiency of 10-12 baskets per minute, this machine significantly improves the speed of mushroom basket transfer while reducing labor dependency. It helps mushroom farms achieve a more efficient workflow, especially during large-scale harvesting periods when fast basket movement is required.
By integrating the SUMXH12A with other mushroom automation equipment, growers can build a complete intelligent cultivation system covering bag preparation, sterilization, inoculation, cultivation, unloading, and harvesting.
Working Principle
Positioning the Machine at the Cultivation Shelf
The unloading machine is positioned near the mushroom growing shelf system.
The equipment is designed to match multi-layer cultivation racks and can adjust according to different shelf heights.
Automatic Detection and System Initialization
After starting operation, the PLC control system automatically checks:
- Machine operating status
- Shelf position
- Basket loading condition
- Safety operation parameters
If an abnormal situation occurs, the system activates the fault alarm function.
Shelf Height Adjustment
According to the preset shelf layer information, the machine automatically adjusts the working height.
This allows the equipment to handle different cultivation shelf structures and improve operational flexibility.
Automatic Basket Extraction
The machine automatically transfers mushroom cultivation baskets from the growing shelf.
The controlled movement ensures:
- Stable basket handling
- Accurate positioning
- Reduced manual labor
- Lower risk of basket damage
Automatic Basket Transfer
After removing the baskets from the shelf, the machine transfers them to the designated unloading position or transportation system.
The system supports:
- Single-row unloading
- Double-row unloading
This improves transfer efficiency and adapts to different factory layouts.
Continuous Automatic Operation
After completing one unloading cycle, the machine automatically continues with the next basket.
The PLC system continuously monitors operation conditions to maintain stable performance.
Suitable Raw Materials and Mushroom Types
It is suitable for cultivation materials including:
Sawdust-based mushroom substrate bags
Wood chip substrate bags
Corn cob-based substrate
Cottonseed hull substrate
Agricultural waste-based mushroom substrate
It is widely used for:
Oyster Mushroom (Pleurotus ostreatus)
Suitable for large commercial bag cultivation farms.
King Oyster Mushroom (Pleurotus eryngii)
Supports industrial multi-layer shelf cultivation.
Shiitake Mushroom (Lentinula edodes)
Suitable for shelf-based sawdust bag cultivation systems.
Black Fungus (Auricularia auricula-judae)
Suitable for short-bag cultivation production.
Other Bag-Grown Edible Mushrooms
Including:
- Enoki mushroom
- Seafood mushroom
- Agrocybe mushroom
Other commercial edible fungi varieties
Capacity / Production Scale
The SUMXH12A provides an unloading efficiency of:
10-12 cultivation baskets per minute
It is designed for:
- Large mushroom cultivation factories
- Commercial growing rooms
- Multi-layer shelf cultivation farms
- Automated edible fungi production facilities
Compared with manual unloading, it provides:
✔ Faster basket transfer
✔ Reduced labor requirements
✔ Improved production efficiency
✔ More stable operation
✔ Lower physical workload for workers
The machine is especially useful during large-scale harvesting and production turnover periods when a large number of cultivation baskets need to be moved quickly.
Automation Level
The SUMXH12A is equipped with an intelligent automatic control system.
Automation functions include:
✔ PLC intelligent control
✔ Automatic basket detection
✔ Automatic shelf positioning
✔ Adjustable shelf-layer control
✔ Single/double-row operation adjustment
✔ Fault detection and alarm system
✔ Manual operation mode for adjustment and maintenance
The operator mainly performs parameter settings, monitoring, and routine maintenance.
Integration with Mushroom Production Line
Upstream Equipment Connection
Mushroom Cultivation Equipment
- Mushroom shelf loading machine
- Mushroom growing room system
- Environmental control equipment
- Humidification system
Bag Production → Sterilization → Inoculation → Shelf Loading → Mushroom Cultivation → Shelf Unloading
Downstream Equipment Connection
Harvesting and Processing Equipment
- Mushroom harvesting workstation
- Mushroom sorting equipment
- Packaging equipment
- Basket transportation system
Logistics Equipment
- Conveyor system
- Automated transport system
- Storage area handling equipment
Cultivation Room → Automatic Unloading → Transportation → Harvesting → Processing → Packaging
Service & FAQ
Installation & Service
We provide professional support to ensure stable machine operation.
Services include:
- Equipment installation guidance
- Cultivation room layout planning
- Shelf compatibility adjustment
- Machine commissioning support
Training includes:
- Equipment operation procedures
- PLC control system usage
- Automatic/manual mode switching
- Daily maintenance methods
Available services:
- Original spare parts supply
- Wearing parts replacement
- Maintenance guidance
Support includes:
- Remote technical assistance
- Equipment troubleshooting
- Operation optimization suggestions
We provide:
- Long-term technical consultation
- Equipment maintenance support
- Production line expansion solutions
FAQ
The machine can unload approximately 10-12 cultivation baskets per minute, making it suitable for large-scale mushroom cultivation factories.
Yes. The machine supports adjustable shelf layers and single-row or double-row operation, allowing adaptation to different cultivation room designs.
It is suitable for bag cultivation systems including oyster mushroom, king oyster mushroom, shiitake mushroom, black fungus, enoki mushroom, and other edible fungi.
The SUMXH12A supports automatic operation. Workers mainly perform monitoring, parameter adjustment, and maintenance instead of continuous manual unloading.
Yes. It can be connected with shelf loading machines, growing room systems, environmental control equipment, conveyors, harvesting systems, and packaging equipment to create an automated mushroom production workflow.
